WEE Technology DO-201AD Ultra-Low VF 3A and 5A 100V SB Series Diodes

Data: 2018-06-08
WEE Technology Company Limited
Manufacturer of Surface Mount (SMD) and Through Hole (DIP) Diodes & Rectifiers

WEET DO-201AD Ultrafast Low VF 3A and 5A 100V SB Series Diodes and Rectifiers, Ultra-Low Forward Voltage Drop Schottky Barrier Rectifier
Please refer to below table, other series are available upon request, please send your enquiry to our sales engineers.

VRM IF (AVG) Products Package Low VF (max.)
40 Volts 3A SB340L DO-201AD(DO-27) 0.4
20 to 100 Volts 5A SB520L THRU SR5100L DO-201AD(DO-27) 0.45,0.55,0.70
45 Volts 5A SB545L DO-201AD(DO-27) 0.4
100 Volts 5A SB5100L DO-201AD(DO-27) 0.64
20 to 100 Volts 5A SR502L THRU SR510L DO-201AD(DO-27) 0.45,0.55,0.70
100 Volts 3.0A / 5.0A SR5100L THRU SR3100L DO-201AD(DO-27) 0.6/0.68
